Main Features
[ZigBee 3.0 Protocol] For stable ZigBee smart switch operation, please use it with a Tuya ZigBee hub/ gateway. And please ensure that the gateway's firmware version meets the version specified on the product description
[Advanced Safety & Robust Performance] Equipped with over-current, high power, and high CPU temperature protection. Features a high-capacity latching relay, supports 1-63A adjustable current, and complies with IEC 60947 standard. For maximum safety, use with a circuit breaker.
[Effortless DIY Installation] Convert traditional home appliances into smart devices in just 10 minutes. It features a 35mm standard DIN Rail mounting system. Equipped with tool-friendly screws, it accepts cables up to 10mm² on both the power and load sides.
[Full Voice & App Control] Operate your devices from anywhere using the "Smart Life" or "Tuya" app. Enjoy complete hands-free control with full compatibility for Amazon Alexa and Google Assistant voice commands.
[Energy Monitoring & Smart Scheduling] Track real-time current, voltage, and power consumption with detailed historical data. Utilize four timing modes—Schedule, Countdown, Cycle, and Astronomical—to automate your devices and save energy.
[Premium Build & Wide Compatibility] Constructed with high-conductivity copper components and flame-retardant PA66 material for durability and safety. Perfect for controlling resistive loads like heaters, incandescent lamps, and ovens (AC1 applications).
A note on Zigbee gateway adaptability
TO-Q-SY2-JZT is a zigbee rail smart switch made by tongou, 35mm rail design can be seamlessly integrated with home power distribution box, currently supports zigbee2mqtt. through the tuya smart life can be remote control, parameter adjustment, power metering, timing, etc.
TO-Q-SY2-JZT is an upgraded version of TO-Q-SY1-JZT, on the basis of which it has added circuit protection functions such as overload protection, short-circuit protection, over-voltage and under-voltage protection, high-temperature protection, which enhances the functionality.
CE CERTIFICATE: TO-Q-SY2-JZT has passed the French ce certification, the quality of the product is guaranteed, guarding the family security, creating a smart home.
Main Features:
Zigbee 3.0 protocol: This Zigbee smart switch must be used in conjunction with a TUYA Zigbee hub/gateway (must correspond to the corresponding firmware version mentioned on the detail page).
Premium material: Zigbee intelligent switches are made of premium material, copper has good conductivity, flame retardant PA66 material, high temperature resistance and effectively improves user safety.
Zigbee Switch: this item is a ZigBee switch with overcurrent protection and undervoltage protection and over-undervoltage protection and temperature protection, the rated current is adjustable in app, 1-63A.
Safe To Use: equipped with coloured indicator lights, you can check the operating status at a glance. Intelligent protection, easy to use, reliable, supports overcurrent protection, etc.
Universal Connected Home DIY Modules: use the SY2 smart switch to switch the small devices of your home from conventional to smart in less than 10 minutes. With this small Zigbee switch, you can transform a lamp, fan or auxiliary heater into a networked object, for example.
App Remote Control: you can control your household appliances via the "Smart Life" app or "Tuya". There are no restrictions on distance and time. The "Smart Life" app can be downloaded from the App Store and Google Play.
Energy Consumption Control: analyse the real-time and historical power consumption of the connected device, time display of load current, voltage and power, logging (hours, days, months and years).
Zigbee Switch With Voice Control: the connected Zigbee switch is compatible with voice control from Amazon Alexa and Google Assistant, you can turn your devices on or off by voice command. With the SY2 switch, you have your hands free.
Timing Mode: the Zigbee intelligent switch has a timing mode. The connected universal switch saves you forgetting to turn off your devices. Adjust the operating hours of your devices to your needs to avoid unnecessary energy loss and achieve energy savings.
Easy Installation and Wide Usability: you can connect the smart switch to your devices in less than ten minutes. You just need to press and insert the cables to complete the wiring. Tightening and loosening the screws is very easy with a screwdriver.
| Item Model Number | TO-Q-SY2-JZT |
| Switch Style | Din Rail Smart Zigbee switch |
| Switch Type | 1P+N (N Pole straight) |
| Manufacturer | Changyou |
| Brand | Tongou |
| Application | Smart Life, Smart Electric, Tuya |
| Third party support | Home Assistant, Zigbee2MQTT |
| Poles description | 1P+N (Direct N Pole) |
| Function | Timing, Countdown, Loop timing, Metering, Over Current, Under Voltage, Over Voltage, Over Power, High Temperature Protection |
| Rated Current (In) | 1 – 63A Adjustable |
| Operating voltage Range | AC 90V – 240V |
| Rated Frequency | 50Hz/60Hz |
| Control Type | Remote, Manual |
| Communication Protocol | Zigbee 3.0 |
| Operating system support | Android, iOS, HarmonyOS |
| Operating Language | With system language |
| App Language | Follow the operating system language |
| Voice Support | Amazon Alexa, Yandex Alice, Google Assistant |
| Included Components | User manual x1 |
| Batteries Required? | NO |
| Batteries Included? | NO |
Zigbee Smart Switch TO-Q-SY2-JZT Wiring
L
The product according to the expected and fast delivery.
M
Worked as described, with easy integration into my home assistant ZigBee network.
Very happy with Tongou product, well made and works reliably
J
All Super, its function viconou. It is not the first time that I can have it beatiful to ridicule on the edge of the transvantage of good. Can vikoristovuvati in the local schemes.
A
Vidvidka the delivery to the vidylennya ukrposti. Vimikach at the warehouse of the forest on the 14th day when you pay. Having put Yogo into the Test Shield, having connected the ZigBee protocol and smarthome, without any problems. Before the river from the annex, the bagatomovna Struktsiya went. To the city, if you do not match it in the annex, the church is alive: evil N and on the right L, call navpaki. Through my friends, I planned to get into the control board for the post-life koristuvannya. Yakshchi viyavlya shoals, vidguk I will.
P
That is some great circuit breaker. Have under/over voltage cutoff, same for temperature and power. Saving state without switching in case outage. Recommended
